Resin Diamond Fluting Wheels

Model: BL-DFMB03
Specification: D100x10R5X22.23H/D100x12R6x22.23H/D100x16R8x11012H
Grit: 36#,50#,100#,200#,400#,800#,1500#,3000#
Application:Fluting & Grinding & Polishing

Send Inquiry

Description

Products Description

Diamond fluting wheel for marble profiling

Resin Diamond Fluting Wheels

SHANZHI Diamond Fluting Wheels are high-performance tools designed for fluting and grinding stone (granite, marble) and concrete surfaces. Crafted with premium diamond polishing materials, these wheels are ideal for achieving precise finishes on a variety of stone products. They are widely used in the stone industry for fluting drain boards, fireplace surrounds, and other decorative marble and granite pieces.

These Stone grinding wheels for precision fluting ensure consistent performance and long-lasting durability, making them the perfect choice for high-volume industrial applications. Whether you are working with granite, marble, or concrete, SHANZHI wheels provide superior cutting and grinding precision, even in the most demanding environments.

Products Details

Diamond polishing fluting wheels for large-scale stone projects

Stone grinding wheels for precision fluting Features：

- Efficient Cutting: The toothed design can quickly break through hard materials, greatly improving processing efficiency.

- Strong Durability: The Diamond fluting wheel material is durable and wear-resistant, with a long service life, reducing the cost of frequent replacement.

- Fine Surface: The Diamond fluting wheel - like structure can achieve high - precision grinding, and the processed surface is smooth and flat.

- Wide Application: It can meet the different processing needs of various hard materials (such as stone, metal, etc.).

Products Specification

Specification	Grit	Thickness	Arbor
4"/100mm Segmented Fluting Wheel Wet,#36	36#	10mm/16mm	7/8(22.23mm)
4"/100mm Electroplated Fluting Wheel Wet,#50	50#	10mm/16mm	7/8(22.23mm)
4"/100mm Resin Fluting Wheel Wet,#100	100#	10mm/16mm	7/8(22.23mm)
4"/100mm Resin Fluting Wheel Wet,#200	200#	10mm/16mm	7/8(22.23mm)
4"/100mm Resin Fluting Wheel Wet,#400	400#	10mm/16mm	7/8(22.23mm)
4"/100mm Resin Fluting Wheel Wet,#800	800#	10mm/16mm	7/8(22.23mm)
4"/100mm Resin Fluting Wheel Wet,#1500	1500#	10mm/16mm	7/8(22.23mm)
4"/100mm Resin Fluting Wheel Wet,#3000	3000#	10mm/16mm	7/8(22.23mm)

Other specifications can be customized according to requirements. All of our products have been strictly tested before access to market.

Products Application

Custom diamond fluting wheel for ceramic

Durable resin diamond fluting wheels for bulk orders

Products Packing

wholesale resin diamond fluting wheels for stone industry

industrial resin diamond grinding wheels supplier

Packaging box can effectively protect the tool's cutting edge and surface from collision and scratch, maintaining the processing accuracy.

Products Exhibition

Products Description

Production Line and Packing 01

FAQ

01.What are the uses of these two grinding wheels respectively?

The toothed grinding wheel on the left is mainly used for rough grinding and scabbling of stone and concrete. Its gear - like structure can quickly create a rough surface to enhance material adhesion. The diamond grinding wheel on the right is suitable for stone polishing and fine grinding, which can make the surfaces of marble, granite, etc. show a mirror - like luster. It can also be used for fine trimming of stone edges and special - shaped surfaces.

02.What are the maintenance precautions?

Clean the debris on the surface of the grinding wheel in time after operation to avoid residual substances affecting the next use effect. If the teeth of the left grinding wheel are severely worn or the diamond layer of the right grinding wheel is significantly thinned, it is necessary to replace them in time to ensure the processing efficiency and quality.

03.How to choose and use them in combination?

When renovating stones or dealing with the base layer, first use the left grinding wheel for rough grinding and scabbling, and then use the right diamond grinding wheel for gradual polishing. For new stone processing, you can directly use the right grinding wheel to complete the polishing from coarse to fine (with different grit diamond grinding wheels). The specific combination needs to be adjusted according to the type of stone and the requirements for the final effect.

04.How about their service life?

The left grinding wheel uses cemented carbide teeth and can handle thousands of square meters in regular rough grinding operations. The service life of the right diamond grinding wheel is related to the hardness of the stone and the intensity of use. When polishing relatively soft stones such as marble, its service life can reach tens of thousands of square meters, and the service life will be shortened accordingly when polishing hard stones such as granite.

05.How about their service life?

The standard of sprockets can be determined according to different application requirements. The difference between metric sprockets and sprockets built to ANSI standards is that they use different units of measurement for chain specifications.
